100BASE-T SFP (Small Form Pluggable) Copper Transceiver Fiber Optic Transceiver Module 100m

100BASE-T SFP (Small Form Pluggable) Copper Transceiver Fiber Optic Transceiver Module 100m

Brand Name: Optowix
Model Number: MU1B-0XT3
MOQ: 10pcs
Payment Terms: T/T
Supply Ability: 10Kpcs
Detail Information
Place of Origin:
China
Certification:
CE
Product Name:
100BASE-T SFP (Small Form Pluggable) Copper Transceiver Module
Optowix PN:
MU1B-0XT3
SpeedRate:
155M
Distrance:
100m
Operating Case Temperature:
0◦C To 70◦C
Packaging Details:
ESD plastic case
Supply Ability:
10Kpcs
Product Description

100BASE-T SFP (Small Form Pluggable) Copper Transceiver Module



Features

  • Up to 125Mb/s bi-directional data links

  • Compliant with SFP MSA
  • Hot-pluggable SFP footprint
  • Support 100BASE-T full duplex default operating mode
  • Support 100BASE-T operation in host systems
  • Auto-sense MDI/MDIX
  • Single power supply 3.3V
  • RoHS Compliant
  • Operating case temperature: 0~+70°C



Applications

  • 125 Mb/s Fast Ethernet

Standards

  • IEEE 802.3
  • SFP MSA

Ordering information



Part Number Description Length
MU1B-0XT3 100BASE-T SFP Copper RJ-45 Connector 100m, commercial temperature 100m
  Notes:

1. The product with write protection.

2. Product ID is the short order number of our product standard model.



Description

  • MU1B-0XT3 copper SFP transceivers are based on Fast Ethernet IEEE 802.3 standard and 100BASE-T standard and provide a quick and reliable interface for the FE application. In addition, they comply with the Small Form Factor Pluggable Multi-Source Agreement (MSA)

General Specifications
